EWI Recessed Plinth to just below ground [Version ID #38]
Detail summary
Detail of recessed plinth for EWI where the internal floor is solid beneath the finished floor level. EWI carried down to 300mm minimum below internal floor level to prevent cold bridging, but stopped short of external ground level
Technical description
- Section detail 200mm EWI Perimeter insulation to below internal floor level.
-Applicable where internal floor continuous for +300mm below internal finished floor level.
Parts list
No parts have been included in this revision of the detail.
Revisions
-
Admin - 2015-05-01 08:52:22
DWG and PDF file drawing file title updated to match title on site, and to avoid duplicate information.
| -
Admin - 2015-04-29 11:40:10
EW01 parts list updated. DWG uploaded.
| -
Admin - 2015-03-27 16:27:53
Preview image and .pdf file updated.
| -
Admin - 2015-03-27 12:57:40
Base plinth added to parts list
| -
Admin - 2015-03-23 16:58:09
General re-formatting. Parts list updated to latest revision.
| -
Admin - 2015-03-23 16:56:35
General re-formatting. Parts list updated to latest revision.
| -
Admin - 2015-03-12 17:09:27
Version 2- Parts list updated. Technical description expanded.
| -
Admin - 2015-02-27 15:29:27 [Displayed version]
Version 1
|
