Roof insulation at rafters [Version ID #86]
Detail summary
Detail for the installation of insulation to rafters as part of loft insulation works. Insulation in plane of rafters where existing roof membrane is non-breathable. Need to ensure adequate ventilation behind insulation
Technical description
Section detail. Roof insulation. Insulation to existing room in roof with impermeable sarking.
Removal of existing ceiling and finishes (set aside for re-use), remove existing light fittings and set aside for re-use. Remove any existing timber mouldings. Check roofing membrane before installation of insulation.
Parts list
-
Insulation Boards Or Batts Fitted Between Rafters
Formaldehyde Free Glass mineral wool semi rigid batts friction fitted between rafters. \ Thickness: 35mm less than rafter depth. Width to suit rafter spacing. \ U-value: 0.032 W/m2k. GWP 0.
Knauf \ www.knaufinsulation.co.uk \ Reference: DriTherm Cavity Slabs.
Revisions
-
Admin - 2015-04-30 10:51:46
DWG uploaded. General re-formatting.
| -
Admin - 2015-03-30 11:19:06
Preview image and pdf detail file updated.
| -
Admin - 2015-03-18 10:29:04
Version 3- Parts list html. text updated to remove errors.
| -
Admin - 2015-03-18 10:04:15
Version 2- Introduction expanded with U-value targets. Technical description expanded with BS and approved doc links. Suggested sequence and reference spec. expanded. Parts list updated with codes and links.
| -
Admin - 2015-03-04 13:49:00 [Displayed version]
First version
|
