External wall insulation detail with window to eaves [Version ID #13]
Detail summary
Detail for new EWI to join to overhanging eaves insulation above an existing window directly below the existing soffit.
Technical description
EWI junction detail to an existing soffit with an existing window (to be replaced) below eaves. Window replacement with triple glazed window with new timber frame.
